Product advantage

- Comply with TIA/EIA 568-B.2-1, ANSI/TIA 568.2-D Cat.6 and ISO/IEC 11801 2nd Class E.

- A cross frame is provided to isolate the pairs of Cat.6 Cable of multi stranded copper strands, with a transmission bandwidth of 250MHz.

- The outer skin is made of standard flame-retardant material, and can be selected with flame-retardant PVC or LSOH low smoke halogen-free.

- It adopts mechanical rubber filled protective sleeve and has RJ45 shrapnel protection design.

- It can provide jumpers of eight colors, meeting tia-606 color management standard.

- Comply with ROHS 2011/65/eu environmental protection standards.

Product characteristics

RJ45 connector conforms to ul/csa FCC part 68, sub part F

Cable insulation material conforms to UL-94V-0

Contact plating: 50μ Gold Plated / 100μ plate with nickel

Interface plugging times: >1000 (IEC 603.7/classa)

Plug and pull resistance: minimum 30lbs (133n) between plug and interface

Maximum DC resistance: <9.38 Ω /100m at 20 ℃

Mutual capacitance: <5.6nf/100m

Applicable temperature: -20 ℃ to +75 ℃

Insulation strength (conductor conductor):1000v, 60hz/1min

Insulation strength (conductor wire split grid):1500v, 60hz/1min

Insulation impedance: >500m ohms (500VDC)

Contact impedance: <35m ohm

Working voltage: ≤ 50V

Inner conductor gauge: 24AWG stranded or solid copper

Cable sheath material: PVC or LSOH in accordance with IEC 60332-1-2

Meet the standards

TIA/EIA 568-B.2

ANSI/TIA 568.2-D

ISO/IEC 11801 2nd Edition

EN 50173 2nd Edition

EN 55022 Class B

Can be used

10/100Base-T

1000Base-T(Gigabit Ethernet)

1.2/2.4 Gbps ATM

TP-PMD(ANSI X3T9.5 100Mbps)

4/16Mbps Token Ring

ISDN、VoIP

PoE+ compliant
