FL-RJC6U Cat.6 RJ45 Unshielded Plug

01.jpg      02.jpg


Product advantage

-Comply with ANSI / TIA 568.2-D and TIA / EIA 568-B.2 Cat.6 standards.

-Repeatedly plug and unplug more than 1000 times.

-The gold plating of contact surface shall comply with UL / CSA FCC part 68 standard.

-Comply with ROHS 2011 / 65 / EU environmental protection specifications and standards.


Product characteristics

Plastic insulation material, polycarbonate, conforming to UL-94V-0

Contact plating: 50¦Ì Gold plating+ 100¦Ì plate with nickel

Surface material voltage withstand strength: 1000V DC

Applicable temperature: - 20 ¡æ ~ + 75 ¡æ

Pull resistance of plug and pull: minimum 11lbf (50N)

Interface plugging times: > 1000

Insulation strength (conductor conductor): 1000VAC, 60Hz / 1min

Insulation impedance: > 500M ohms (500VDC)

Rated voltage / current: 150VAC / 1.5Ampere

Applicable wire: 23AWG ~ 26AWG (Multi Strand & single strand)


Meet the standards

TIA/EIA 568-B.2-1 Category 6

ANSI/TIA 568.2-D Category 6

ISO/IEC 11801 2nd Edition


Can be used

10/100Base-T

1000Base-T

2.5G/5GBase-T

TP-PMD(ANSI X3T9.5 100Mbps)

ISDN

VoIP

PoE+




Order information

Order information.jpg


EIA Standard wiring mode

EIA Standard wiring mode.jpg


P2.06.14_Cat.6 RJ45 Unshielded Plug.pdf


P2.06.14_ÁùÀà·ÇÆÁ±ÎRJ45Ë®¾§Í·.pdf
